Audio:
Realtek® ALC1200 codec
|
|
Chipset:
AMD X570
|
|
CPU:
AMD Socket AM4, support for- AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ with Radeon™ Vega Graphics Processors
|
|
Features:
Support for APP Center, @BIOS, EasyTune, Fast Boot, Game Boost, ON/OFF Charge, RGB Fusion, Smart Backup, System Information Viewer, Q-Flash Plus, Q-Flash, Xpress Install
|
|
Form Factor:
ATX Form Factor
|
|
Graphics:
Integrated Graphics Processor
|
|
LAN:
Intel® GbE LAN chip
|
|
Memory:
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory, Dual channel memory architecture, Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200(O.C.) / 2933 / 2667 / 2400 / 2133 MHz memory modules
|
|
Operating System:
Windows 10 64 bit/ Windows 11 64 bit
|
|
USB Ports:
Integrated in the CPU- 4 x USB 3.2 Gen 1 ports
|
|
Warranty:
3 Years
|
|
Wireless Standard:
Wi-Fi 802.11 a/b/g/n/ac, BLUETOOTH 4.2
|
|
Storage Interface:
Integrated in the CPU (M2A_SOCKET)- AMD Ryzen™ 5000 Series/ 3rd Gen Ryzen™ Processors
|
|
Internal I/O Connectors:
1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x CPU fan header, 1 x water cooling CPU fan header, 2 x system fan headers, 2 x addressable LED strip headers, 2 x RGB LED strip headers, 1 x CPU cooler LED strip/RGB LED strip header, 2 x M.2 Socket 3 connectors, 6 x SATA 6Gb/s connectors, 1 x front panel header, 1 x front panel audio header, 1 x USB Type-C™ port, with USB 3.2 Gen 2 support, 2 x USB 3.2 Gen 1 headers, 2 x USB 2.0/1.1 headers, 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only), 1 x Clear CMOS jumper, 1 x Q-Flash Plus button
|
|
Back Panel Connectors:
4 x USB 2.0/1.1 ports, 2 x SMA antenna connectors (1T1R), 1 x HDMI port, 4 x USB 3.2 Gen 1 ports, 2 x USB 3.2 Gen 2 Type-A ports (red), 1 x RJ-45 port, 1 x optical S/PDIF Out connector, 5 x audio jacks
|
|
I/O Controller:
iTE® I/O Controller Chip
|
|
H/W Monitoring:
Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Overheating warning, Fan fail warning, Fan speed control
|
|
BIOS:
1 x 128 Mbit flash
|
|
Bundled Software:
Norton® Internet Security (OEM version), cFosSpeed
|
|
Chipset+2 USB 2.0 Hubs:
8 x USB 2.0/1.1 ports
|
|
Integrated in the Chipset (M2B_SOCKET):
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0/3.0 x4/x2 SSD support), 6 x SATA 6Gb/s connectors, Support for RAID 0, RAID 1, and RAID 10,
1 x USB Type-C™ port with USB 3.2 Gen 2, 2 x USB 3.2 Gen 2 Type-A ports (red), 4 x USB 3.2 Gen 1 ports
|
