B550 AORUS PRO AC (rev. 1.x)

• CPU
  • AMD Socket AM4, support for - AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 Series Processors
• Chipset
  • AMD B550
• Memory
  • 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory, Support for DDR4 5400(O.C.) / 5300(O.C.) / 5200(O.C.) / 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules, Dual channel memory architecture
• Graphics
  • Integrated Graphics Processor
• Audio
  • Realtek® ALC1220-VB codec
• LAN
  • Realtek® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
• Wireless Standard
  • Wi-Fi module, BLUETOOTH 4.2
• Expansion Slots
  • 1 x PCI Express x16 slot (PCIEX16), 1 x PCI Express x16 slot (PCIEX4), 1 x PCI Express x16 slot (PCIEX2), 2 x PCI Express x1 slots
• Storage Interface
  • 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs, 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs, 6 x SATA 6Gb/s connectors, integrated in the Chipset
• USB Ports
  • CPU:3 x USB 3.2 Gen 1 ports, 1 x USB 3.2 Gen 2 Type-A port (red)
• Chipset
  • 1 x USB Type-C™ port, 1 x USB 3.2 Gen 2 Type-A port (red), 2 x USB 3.2 Gen 1 ports, 2 x USB 2.0/1.1 ports
• Chipset+2 USB 2.0 Hubs
  • 8 x USB 2.0/1.1 ports
• Internal I/O Connectors
  • 1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 2 x M.2 Socket 3 connectors, 6 x SATA 6Gb/s connectors, 1 x CPU fan header, 1 x water cooling CPU fan header, 4 x system fan headers, 2 x system fan/water cooling pump headers, 1 x CPU cooler LED strip/RGB LED strip header, 2 x addressable LED strip headers, 2 x RGB LED strip headers, 1 x front panel header, 1 x front panel audio header, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers, 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only), 2 x temperature sensor headers, 1 x Thunderbolt™ add-in card connector, 1 x Clear CMOS jumper, 1 x Thunderbolt header
• Back Panel Connectors
  • 1 x HDMI port, 2 x SMA antenna connectors (1T1R), 3 x USB 3.2 Gen 1 ports, 1 x USB Type-C™ port, with USB 3.2 Gen 2 support, H642 x USB 3.2 Gen 2 Type-A ports (red), 6 x USB 2.0/1.1 ports, 1 x Q-Flash Plus button, 1 x RJ-45 port, 1 x optical S/PDIF Out connector, 5 x audio jacks
• I/O Controller
  • iTE® I/O Controller Chip
• H/W Monitoring
  • Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Overheating warning, Fan fail warning, Fan speed control
• BIOS
  • 1 x 256 Mbit flash
• Features
  • Support for APP Center, @BIOS, EasyTune, Fast Boot, Game Boost, ON/OFF Charge, RGB Fusion, Smart Backup, System Information Viewer, Q-Flash Plus, Q-Flash, Xpress Install
• Bundled Software
  • Norton® Internet Security (OEM version), XSplit Gamecaster + Broadcaster (12 months license), Realtek® 8125 Gaming LAN Bandwidth Control Utility
• Operating System
  • Support for Windows 11/10 64-bit
• Form Factor
  • Micro ATX Form Factor
• Warranty
  • 3 Years
