CPU:
LGA1700 socket- Support for 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
|
|
Chipset:
Intel® B660 Express Chipset,
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_SB), 4 x SATA 6Gb/s connectors, Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10
|
|
Memory:
Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200/3000/2933/2666/2400/2133 MHz memory modules, Dual channel memory architecture
|
|
Graphics:
Integrated Graphics Processor-Intel® HD Graphics support
|
|
Audio:
Realtek® Audio CODEC
|
|
LAN:
Intel®2.5GbE LAN chip
|
|
Expansion Slots:
1 x PCI Express x16 slot, 1 x PCI Express x16 slot, running at x4 (PCIEX4), 1 x PCI Express x1 slot
|
|
Storage Interface:
CPU- 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
|
|
USB Ports:
Chipset- 1 x USB Type-C® port, 1 x USB Type-C® port, 1 x USB 3.2 Gen 2 Type-A port (red)
|
|
Chipset+2 USB 3.2 Gen 1 Hubs:
6 x USB 3.2 Gen 1 ports
|
|
Chipset+2 USB 2.0 Hubs:
8 x USB 2.0/1.1 ports
|
|
Internal I/O Connectors:
1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x 4-pin ATX 12V power connector, 1 x CPU fan header, 1 x water cooling CPU fan header, 3 x system fan headers, 1 x system fan/water cooling pump header, 2 x addressable LED strip headers, 2 x RGB LED strip headers, 2 x M.2 Socket 3 connectors, 4 x SATA 6Gb/s connectors, 1 x front panel header, 1 x front panel audio header, 1 x USB Type-C® header, with USB 3.2 Gen 2 support, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers, 2 x Thunderbolt™ add-in card connectors, 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only), 1 x serial port header, 1 x reset button, 1 x Q-Flash Plus button, 1 x reset jumper, 1 x Clear CMOS jumper
|
|
Back Panel Connectors:
1 x USB Type-C® port, 1 x USB 3.2 Gen 2 Type-A port (red), 4 x USB 3.2 Gen 1 ports, 4 x USB 2.0/1.1 ports, 1 x HDMI port, 1 x DisplayPort, 1 x RJ-45 port, 1 x optical S/PDIF Out connector, 2 x audio jacks
|
|
I/O Controller:
iTE® I/O Controller Chip
|
|
H/W Monitoring:
Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control
|
|
BIOS:
1 x 256 Mbit flash
|
|
Features:
Support for APP Center, @BIOS, EasyTune, Fast Boot, Game Boost, ON/OFF Charge, RGB Fusion, Smart Backup, System Information Viewer, Q-Flash Plus, Q-Flash, Xpress Install
|
|
Bundled Software:
Norton® Internet Security (OEM version), cFosSpeed
|
|
Operating System:
Support for Windows 11/10 64-bit
|
|
Form Factor:
Micro ATX Form Factor
|
|
Warranty:
3 Years
|
