Chipset:
Intel® H470 Express Chipset
|
|
CPU:
Support for 10th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1200 package
|
|
Expansion Slots:
1 x PCI Express x16 slot, running at x16 (PCIEX16), 1 x PCI Express x16 slot, running at x4 (PCIEX4), 3 x PCI Express x1 slots
|
|
Features:
Support for APP Center, @BIOS, EasyTune, Fast Boot, Game Boost, ON/OFF Charge, RGB Fusion, Smart Backup, System Information Viewer, Q-Flash Plus, Q-Flash, Xpress Install
|
|
Form Factor:
ATX Form Factor
|
|
Graphics:
Integrated Graphics Processor-Intel® HD Graphics Audio
|
|
LAN:
Intel® 2.5GbE LAN chip
|
|
Memory:
Intel® Core™ i9/i7 processors
|
|
Operating System:
Support for Windows 10 64-bit
|
|
USB Ports:
Chipset- 1 x USB Type-C™ port, 1 x USB 3.2 Gen 2 Type-A port (red), 6 x USB 3.2 Gen 1 ports, 2 x USB 2.0/1.1 ports on the back panel
|
|
Warranty:
3 Years
|
|
Wireless Standard:
Intel® Wi-Fi 6 AX201, WIFI a, b, g, n, ac, BLUETOOTH 5.1
|
|
Storage Interface:
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2A_SB), 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4/x2 SSD support) (M2M_SB), 6 x SATA 6Gb/s connectors, Support for RAID 0, RAID 1, RAID 5, and RAID 10
|
|
Internal I/O Connectors:
1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x CPU fan header, 1 x water cooling CPU fan header, 3 x system fan headers, 2 x addressable LED strip headers, 2 x RGB LED strip headers, 1 x Q-Flash Plus button, 6 x SATA 6Gb/s connectors, 2 x M.2 Socket 3 connectors, 1 x front panel header, 1 x front panel audio header, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers, 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only), 2 x Thunderbolt™ add-in card connectors, 1 x serial port header, 1 x Clear CMOS jumper
|
|
Back Panel Connectors:
1 x PS/2 keyboard/mouse port, 2 x SMA antenna connectors (2T2R), 1 x HDMI port, 1 x DisplayPort, 1 x USB 3.2 Gen 2 Type-A port (red), 1 x USB Type-C™ port, with USB 3.2 Gen 2 support, 4 x USB 3.2 Gen 1 ports, 2 x USB 2.0/1.1 ports, 1 x RJ-45 port, 1 x optical S/PDIF Out connector, 5 x audio jacks
|
|
I/O Controller:
iTE® I/O Controller Chip
|
|
H/W Monitoring:
Voltage detection, Temperature detection, Fan speed detection, Overheating warning, Fan fail warning, Fan speed control
|
|
BIOS:
1 x 256 Mbit flash
|
|
Bundled Software:
Norton® Internet Security (OEM version), cFosSpeed
|
|
Chipset+USB 2.0 Hub:
4 x USB 2.0/1.1 ports
|
