CPU:
AM4 Socket- Supports AMD Ryzen™ 5000 series / Ryzen™ 5000 G-Series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 1st Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ 1st Gen Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
|
|
Chipset:
AMD B550,
2 x USB 3.2 Gen 1 ports, 4 x USB 2.0/1.1 ports
|
|
Memory:
2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory, Support for DDR4 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules, Dual channel memory architecture
|
|
Graphics:
Integrated Graphics Processor
|
|
Audio:
Realtek® Audio CODEC
|
|
LAN:
Realtek® GbE LAN chip
|
|
Expansion Slots:
1 x PCI Express x16 slot, 2 x PCI Express x1 slots (PCIEX1_1, PCIEX1_2)
|
|
Storage Interface:
1 x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280 SSDs, 4 x SATA 6Gb/s connectors, Support for RAID 0, RAID 1, and RAID 10
|
|
USB Ports:
CPU:4 x USB 3.2 Gen 1 ports on the back panel, Chipset: 2 x USB 3.2 Gen 1 ports, 6 x USB 2.0/1.1 ports
|
|
Internal I/O Connectors:
1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x CPU fan header, 2 x system fan headers, 1 x addressable LED strip header, 1 x RGB LED strip header, 1 x M.2 Socket 3 connector, 4 x SATA 6Gb/s connectors, 1 x front panel header, 1 x front panel audio header, 1 x speaker header, 1 x USB 3.2 Gen 1 header, 1 x USB 2.0/1.1 header, 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only), 1 x serial port header, 1 x chassis intrusion header, 1 x Clear CMOS jumper
|
|
Back Panel Connectors:
1 x PS/2 keyboard/mouse port, 1 x D-Sub port, 1 x DVI-D port, 1 x HDMI port, 4 x USB 3.2 Gen 1 ports, 2 x USB 2.0/1.1 ports, 1 x RJ-45 port, 3 x audio jacks
|
|
I/O Controller:
iTE® I/O Controller Chip
|
|
H/W Monitoring:
Voltage detection, Temperature detection, Fan speed detection, Overheating warning, Fan fail warning, Fan speed control
|
|
BIOS:
1 x 256 Mbit flash
|
|
Features:
Support for APP Center, @BIOS, EasyTune, Fast Boot, Game Boost, ON/OFF Charge, RGB Fusion, Smart Backup, System Information Viewer, Q-Flash Plus, Q-Flash, Xpress Install
|
|
Bundled Software:
Norton® Internet Security (OEM version), Realtek® 8118 Gaming LAN Bandwidth Control Utility
|
|
Operating System:
Support for Windows 11/10 64-bit
|
|
Form Factor:
Micro ATX Form Factor
|
|
Warranty:
3 Years
|
