CPU:
LGA1200 package-11th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors, 10th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors / Intel® Core™ i3 processors/ Intel® Pentium® processors / Intel® Celeron® processors
|
|
Chipset:
Intel® Z590 Express Chipset,
1 x M.2 connector (Socket 3, M key, type 2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2M_SB), 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 3.0 x4/x2 SSD support) (M2P_SB), 6 x SATA 6Gb/s connectors, Support for RAID 0, RAID 1, RAID 5, and RAID 10,
1 x USB Type-C® port, 2 x USB 3.2 Gen 2 Type-A ports (red), 2 x USB 3.2 Gen 1
|
|
Memory:
11th Generation Intel® Core™ i9/i7/i5 processors
|
|
Integrated Graphics Processor+Intel® Thunderbolt™ 4 Controller:
1 x VisionLINK TB connector (Intel® Thunderbolt™ 4/USB Type-C® port), 1 x Intel® Thunderbolt™ 4 connector (USB Type-C® port)
|
|
Integrated Graphics Processor-Intel® HD Graphics support:
1 x HDMI port
|
|
Audio:
Realtek® ALC4080 codec
|
|
LAN:
2 x Intel® 2.5GbE LAN chips
|
|
Expansion Slots:
1 x PCI Express x16 slot, running at x16 (PCIEX16), 1 x PCI Express x16 slot, running at x8 (PCIEX8), 1 x PCI Express x16 slot, running at x4 (PCIEX4), 1 x PCI Express x1 slot
|
|
Storage Interface:
CPU- 1 x M.2 connector (Socket 3, M key, type 2280/22110 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
|
|
USB Ports:
Chipset+Intel® Thunderbolt™ 4 Controller
|
|
Chipset+USB 3.2 Gen 1 Hub:
4 x USB 3.2 Gen 1 ports
|
|
Chipset+USB 2.0 Hub:
4 x USB 2.0/1.1 ports
|
|
Internal I/O Connectors:
1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x 4-pin ATX 12V power connector, 1 x CPU fan header, 1 x water cooling CPU fan header, 4 x system fan headers, 2 x system fan/water cooling pump headers, 2 x addressable LED strip headers, 2 x RGB LED strip headers, 3 x M.2 Socket 3 connectors, 6 x SATA 6Gb/s connectors, 1 x front panel header, 1 x front panel audio header, 1 x USB Type-C® header, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers, 1 x noise detection header, 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only), 2 x temperature sensor headers, 1 x Clear CMOS jumper, 1 x Q-Flash Plus button
|
|
Back Panel Connectors:
1 x DisplayPort In port, 1 x HDMI port, 2 x SMA antenna connectors (2T2R), 2 x Thunderbolt™ 4 connectors USB Type-C® port, 2 x USB 3.2 Gen 2 Type-A ports (red), 4 x USB 3.2 Gen 1 ports, 2 x RJ-45 ports, 1 x optical S/PDIF Out connector, 5 x audio jacks
|
|
I/O Controller:
iTE® I/O Controller Chip
|
|
H/W Monitoring:
Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control, Noise detection
|
|
BIOS:
1 x 256 Mbit flash
|
|
Features:
Support for APP Center, @BIOS, EasyTune, Fast Boot, Game Boost, ON/OFF Charge, RGB Fusion, Smart Backup, System Information Viewer, Q-Flash Plus, Q-Flash, Xpress Install
|
|
Bundled Software:
Norton® Internet Security (OEM version), cFosSpeed
|
|
Operating System:
Support for Windows 10 64-bit
|
|
Form Factor:
ATX Form Factor
|
|
Warranty:
3 Years
|
|
Wireless Standard:
Intel® Wi-Fi 6 AX200, WIFI a, b, g, n, ac, ax, BLUETOOTH 5.1
|
